Butt weld ASME B16.9 Equal Cross Fitting Manufacturer


Leading ANSI/ASME B16.9 Butt weld Equal Cross Manufacturers and Authoritative SS Equal Cross Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Equal Cross Manufacturers in India

As a leading manufacturer, stockist, and exporters of butt weld equal Cross we are providing high-quality equal Cross pipe fitting at best price in India.

We keep the largest stock of 15mm equal cross, 22mm equal cross, stainless steel equal Cross, carbon steel equal Cross, nickel alloy equal Cross, alloy steel equal Cross, monel equal Cross, copper equal cross, equal cross fitting in all dimension.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD EQUAL CROSS / STAINLESS STEEL BUTT WELD EQUAL CROSS / DUPLEX STEEL BUTT WELD EQUAL CROSS / CARBON STEEL BUTT WELD EQUAL CROSS / ALLOY STEEL BUTT WELD EQUAL CROSS / HASTELLOY STEEL BUTT WELD EQUAL CROSS / MONEL STEEL BUTT WELD EQUAL CROSS / INCONEL STEEL BUTT WELD EQUAL CROSS / TITANIUN STEEL BUTT WELD EQUAL CROSS / SUPER DUPLEX STEEL BUTT WELD EQUAL CROSS / INCOLOY STEEL BUTT WELD EQUAL CROSS / ALLOY 20 BUTT WELD EQUAL CROSS / 254 SMO BUTT WELD EQUAL CROSS/ COPPER NICKEL STEEL BUTT WELD EQUAL CROSS
ANSI/ASME B16.9 Butt weld Equal Cross Exporter in India

ANSI/ASME B16.9 Butt weld Equal Cross Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Equal Cross Materials and Grade

Stainless Steel Butt weld Equal Cross:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Equal Cross:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Equal Cross:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Equal Cross:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Equal Cross in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Equal Cross. We keep intensive stock of Equal Cross Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI Equal Cross. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Equal Cross Fittings using high quality of raw materials and latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Equal Cross Price List

Following is ANSI/ASME B16.9 Butt weld Equal Cross price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Butt Welding Equal Cross ASME B16.9 $1.00-$10.00 USD/Piece
Stainless Steel pipe fitting butt weld equal Cross $1.00-$100.00 USD/Piece
CS butt welded equal cross SCH40 SCH80 $1.00-$100.00 USD/Piece
ANSI/ASME B16.9 Butt weld equal cross fitting $1.00-$100.00 USD/Piece
high pressure steel pipe fitting butt welded equal cross $1.00-$100.00 USD/Piece
seamless steel pipe fitting butt welded equal cross $1.00-$900.00 USD/Piece
Butt Welding Equal Cross A234 WPB Steel 4-way Cross $1.00-$10000.00 USD/Piece
Welding Straight Cross $132.00 USD/Unit
butt weld pipe cross 1-4″ $1.00-$50.00 USD/Piece
SS pipe fittings 4 port butt welding Cross $0.56-$22.00 USD/Piece
sanitary SS pipe fitting butt weld 4 way cross connector $1.00-$25.00 USD/Piece
8 inch carbon steel butt weld pipe cross $0.25-$60.00 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Equal Cross Dimensions:

Nominal Pipe Size (NPS) DN Outside Diameter at Bevel Center- to-End
Run.C Outlet. M[Notes(1) and (2)]
1/2 15 21.3 25 25
3/4 20 26.7 29 29
1 25 33.4 38 38
1-1/4 32 42.2 48 48
1-1/2 40 48.3 57 57
2 50 60.3 64 64
2-1/2 65 73.0 76 76
3 80 88.9 86 86
3-1/2 90 101.6 95 95
4 100 114.3 105 105
5 125 141.3 124 124
6 150 168.3 143 143
8 200 219.1 178 178
10 250 273.0 216 216
12 300 323.8 254 254
14 350 355.6 279 279
16 400 406.4 305 305
18 450 457 343 343
20 500 508 381 381
22 550 559 419 419
24 600 610 432 432
26 650 660 495 495
28 700 711 521 521
30 750 762 559 559
32 800 813 597 597
34 850 864 635 635
36 900 914 673 673
38 950 965 711 711
40 1000 1016 749 749
42 1050 1067 762 711
44 1100 1118 813 762
46 1150 1168 851 800
48 1200 1219 889 838

NOTE: All dimensions are in millimeters.
(a). Outlet dimension M for NPS 26(DN 650) and large is recommended but not required.
(b). Dimensions applicable to crosses NPS 24(DN 600) and smaller.

ANSI/ASME B16.9 Butt weld Equal Cross Application
