What is 180 Degree Long Radius Elbow?

An elbow is a pipe fitting which is widly used as a connection point between two lengths of pipes to produce a change in the direction of flow in the pipe, usually at an angle of 90° (90 degree), 45°(45 degree) or 180° (180 degree). Elbow pipe fitting are also commonly referred as bends, and are available in a range of materials such as nickel alloys, stainless steel, alloy steel, carbon steel, duplex, supper duplex and cupro nickel etc. 180 degree long radius elbow or also called as return bend allows complete reversal of flow. The distance between end of elbow and center line is 3 x NPS.

180 Degree Long Radius Elbow Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

180 Degree Long Radius Elbow Materials and Grade

Stainless Steel 180 degree Long Radius Elbow:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 180 degree Long Radius Elbow:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy 180 degree Long Radius Elbow:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy steel 180 degree Long Radius Elbow:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of 180 degree Long radius elbow in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of ANSI/ASME B16.9 180° Long Radius Elbow. We keep intensive stock of Long radius 180 degree elbow to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of both seamless and welded 180 deg Long radius elbow. We have over 4 decades of experience in manufacturing of ASME B16.9 Butt weld 180 degree Long Radius Elbow using high quality of raw materials and using latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

180 Degree Long Radius Elbow Price List

Following is 180 Degree Long Radius Elbow price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
180 Degree Elbow Long Radius Elbow 1.5D $1.00-$5.00 USD/Piece
Butt-welding Pipe Fittings 180 D Long Radius Elbow $9.75-$30.00 USD/Piece
asme b16.9 long radius 180 degree elbow $420.00-$980.00 USD/Piece
180 degree Long Radius(LR r=1.5d) Elbow $0.50-$99.00 USD/Piece
180 degree long radius elbow sch40 $0.50-$100.00 USD/Piece
180 degree high pressure long radius elbow $40.00-$50.00 USD/Piece
long radius stainless steel 180 degree elbow $1.00-$100.00 USD/Piece
180 degree elbow/bend pipe $600.00-$800.00 USD/Ton
180 degree long radius steel return bend elbow $0.50-$1.00 USD/Kilogram
180 degree carbon welded long radius elbow $0.10-$1000.00 USD/Piece
long radius copper fittings 180 degree elbow $1.00-$100.00 USD/Piece
SCH160 Long Radius 180 degree Elbow $1210.00-$1820.00 USD/Ton
Carbon Steel Long Radius 180 Degree Elbow $1.00-$16.38 USD/Piece
titanium long radius 180 degree pipe elbow 1.5d $4.80-$30.00 USD/Piece
180 degree Elbow $1.00-$1000.00 USD/Piece
dn80 3″ sch80 180 degree long radius smls elbow $0.50-$1.00 USD/Piece
Butt weld pipe fitting Long Radius Elbow 180 degree $1.00-$38.00 USD/Piece
copper pipe fitting 180 degree long radius elbow $5.50-$30.00 USD/Piece

Reference:alibaba

180 Degree Long Radius Elbow Dimensions:

Butt weld 180 degree Long Radius Elbow Dimensions

NPS O.D. D 180° Long Radius
Center to Center
O
Back to Face
K
1/2 21.3 76 48
3/4 26.7 76 51
1 33.4 76 56
42.2 95 70
48.3 114 83
2 60.3 152 106
73 190 132
3 88.9 229 159
101.6 267 184
4 114.3 305 210
5 141.3 381 262
6 168.3 457 313
8 219.1 610 414
10 273 762 518
12 323.8 914 619
14 355.6 1067 711
16 406.4 1219 813
18 457 1372 914
20 508 1524 1016
22 559 1676 1118
24 610 1829 1219

180 Degree Long Radius Elbow Dimensional Tolerance

For all fittings 180° Returns
Nominal Pipe Size (NPS) Outside Ø
at Bevel
Inside Ø
at End
Wall Thickness
t / t1
Center to Center Dim.
O
Back to Face Dim.
K
Align- ment of Ends
U
1/2 a 2 1/2 1 0,8 Not 7 7 1
3 a 3 1/2 1 1,6 less 7 7 1
4 +2 -1 1,6 than 7 7 1
5 a 6 +3 -1 1,6 87,50% 7 7 1
8 2 1,6 of nominal 7 7 1
10 +4 -3 3,2 thickness 7 7 2
12 a 18 +4 -3 3,2 10 7 2
20 a 24 +6 -5 4,8 10 7 2
26 a 30 +7 -5 4,8 ….. ….. …..
32 a 48 +7 -5 4,8 ….. ….. …..

180 Degree Long Radius Elbow Angularity Tolerances

Angularity Tolerances
ND Max off angle Max off plane
Q P
1/2 a 4 1 2
5 a 8 2 4
10 a 12 3 5
14 a 16 3 7
18 a 24 4 10
26 a 30 5 10
32 a 42 5 13
44 a 48 5 20

ANSI/ASME B16.9 180° Long Radius Elbow Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of 180 Degree Long Radius Elbow and supplying to various core industries like

Chemicals Fertilizers Industries

Chemicals Fertilizers Industries
Heat Exchanger

Heat Exchanger
Instrumentation

Instrumentation
Nuclear Thermal Industries

Nuclear Thermal Industries
Oil Gas Industries

Oil Gas Industries
Pharmacy Surgical Industries

Pharmacy Surgical Industries
Refineries Petrochemicals

Refineries Petrochemicals
Water Gas Piping Systems

Water Gas Piping Systems
