What is 180 Degree Short Radius Elbow?

An elbow is a pipe fitting which is widly used as a connection point between two lengths of pipes to produce a change in the direction of flow in the pipe, usually at an angle of 90° (90 degree), 45°(45 degree) or 180° (180 degree). Elbow pipe fitting are also commonly referred as bends, and are available in a range of materials such as nickel alloys, stainless steel, alloy steel, carbon steel, duplex, supper duplex and cupro nickel etc. 180 degree short radius elbow or also called as return bend allows complete reversal of flow but in a much tighter turn. The distance between end of elbow and center line is 1 x NPS.

180 Degree Short Radius Elbow Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Short Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

180 Degree Short Radius Elbow Materials and Grade

Stainless Steel 180 degree Short Radius Elbow:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 180 degree Short Radius Elbow:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy 180 degree Short Radius Elbow:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy steel 180 degree Short Radius Elbow:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of 180 degree Short radius elbow in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of ANSI/ASME B16.9 180° Short Radius Elbow. We keep intensive stock of Short radius 180 degree elbow to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of both seamless and welded 180 deg Short radius elbow. We have over 4 decades of experience in manufacturing of ASME B16.9 Butt weld 180 degree Short Radius Elbow using high quality of raw materials and using latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

180 Degree Short Radius Elbow Price List

Following is 180 Degree Short Radius Elbow price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Asme b16.9 180 Degree Short Radius Elbows $72.00-$75.00 USD/Piece
welded elbow 180 degree angle short radius $0.20-$15.00 USD/Piece
180 degree short radius gr2 titanium elbow $3.50-$50.00 USD/Piece
mild steel 180 degree short radius elbow $300.00-$500.00 USD/Ton
180 Degree Short Radius Carbon Steel Elbow $0.10-$16.70 USD/Piece
180 degree short radius elbow a234 gr wpb $0.50-$100.00 USD/Piece
8 inch 180 degree short radius elbow $100.00 USD/Piece
ASTM WPB A234 180 degree short radius elbow/bend $1.00-$99.00 USD/Piece
Sanitary Stainless Steel 180 Degree Butt Weld Elbow $1.38-$18.98 USD/Piece
180 D Short Radius Elbow Super Duplex Steel $9.75-$80.00 USD/Piece
2”sch40 ASME B16.9 180 Degree SR elbow $1.00-$10.00 USD/Piece
180 degree short radius elbow sch40 $0.50-$100.00 USD/Piece
schedule 40 short radius carbon steel 180 degree $5.00-$100.00 USD/Piece
Stainless Steel Butt Welded Pipe 180 Degree Elbow $2.00-$90.00 USD/Piece
ASME b16.9 180 degree short radius elbow $1.00-$500.00 USD/Piece
carbon steel 180 degree short radius sr 1d elbow $10.50-$50.00 USD/Piece
Welded ASME B16.9 180 Degree Short Radius Elbows $1.00-$100.00 USD/Piece
1/2 inch to 48 inch ansi b16.9 Short Radius elbow 180 Degree $0.35-$330.00 USD/Piece

Reference:alibaba

180 Degree Short Radius Elbow Dimensions:

Butt weld 180 degree Short Radius Elbow Dimensions

NPS O.D.
D
180° Long Radius 180° Short Radius
Center to
Center
O
Back to
Face
K
Center to
Center
O
Back to
Face
K
1/2 21.3 76 48
3/4 26.7 76 51
1 33.4 76 56 51 41
42.2 95 70 64 52
48.3 114 83 76 62
2 60.3 152 106 102 81
73 190 132 127 100
3 88.9 229 159 152 121
101.6 267 184 178 140
4 114.3 305 210 203 159
5 141.3 381 262 254 197
6 168.3 457 313 305 237
8 219.1 610 414 406 313
10 273 762 518 508 391
12 323.8 914 619 610 467
14 355.6 1067 711 711 533
16 406.4 1219 813 813 610
18 457 1372 914 914 686
20 508 1524 1016 1016 762
22 559 1676 1118 1118 838
24 610 1829 1219 1219 914

180 Degree Short Radius Elbow Dimensional Tolerance

DIMENSIONAL TOLERANCES – ELBOWS
For all fittings Elbows 90/45 deg 180° Returns
Nominal Pipe Size (NPS) Outside Ø
at Bevel
Inside Ø
at End
Wall Thickness
t / t1
Center to End Dim. A-B-C-M Center to Center Dim.
O
Back to Face Dim.
K
Align- ment of Ends
U
1/2 a 2 1/2 1 0,8 Not 2 7 7 1
3 a 3 1/2 1 1,6 less 2 7 7 1
4 +2 -1 1,6 than 2 7 7 1
5 a 6 +3 -1 1,6 87,50% 2 7 7 1
8 2 1,6 of nominal 2 7 7 1
10 +4 -3 3,2 tickness 2 7 7 2
12 a 18 +4 -3 3,2 3 10 7 2
20 a 24 +6 -5 4,8 3 10 7 2
26 a 30 +7 -5 4,8 3 ….. ….. …..
32 a 48 +7 -5 4,8 5 ….. ….. …..

180 Degree Short Radius Elbow Angularity Tolerances

Angularity Tolerances
ND Max off angle Max off plane
Q P
1/2 a 4 1 2
5 a 8 2 4
10 a 12 3 5
14 a 16 3 7
18 a 24 4 10
26 a 30 5 10
32 a 42 5 13
44 a 48 5 20

ANSI/ASME B16.9 180° Short Radius Elbow Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of 180 Degree Short Radius Elbow and supplying to various core industries like

Chemicals Fertilizers Industries

Chemicals Fertilizers Industries
Heat Exchanger

Heat Exchanger
Instrumentation

Instrumentation
Nuclear Thermal Industries

Nuclear Thermal Industries
Oil Gas Industries

Oil Gas Industries
Pharmacy Surgical Industries

Pharmacy Surgical Industries
Refineries Petrochemicals

Refineries Petrochemicals
Water Gas Piping Systems

Water Gas Piping Systems
