ANSI/ASME B16.9 45 Degree Long Radius Elbow Manufacturers in India

ANSI/ASME B16.9 45 Degree Long Radius Elbow Manufacturers in India

Manufacturers, Stockist, and Exporter of ANSI/ASME B16.9 45° Long Radius Elbow, Buttweld 45 Degree LR Elbow, Butt weld 45 Deg Long Radius Elbow Supplier in India.

Largest Stock of Long Radius 45 Degree Elbow, 45 Degree Long Radius Reducing Elbow, ASME B16.9 Long Radius Elbow at Best Prices in India.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 45 DEGREE LONG RADIUS ELBOW / STAINLESS STEEL 45 DEGREE LONG RADIUS ELBOW / DUPLEX STEEL 45 DEGREE LONG RADIUS ELBOW / CARBON STEEL 45 DEGREE LONG RADIUS ELBOW / ALLOY STEEL 45 DEGREE LONG RADIUS ELBOW / HASTELLOY STEEL 45 DEGREE LONG RADIUS ELBOW / MONEL STEEL 45 DEGREE LONG RADIUS ELBOW / INCONEL STEEL 45 DEGREE LONG RADIUS ELBOW / TITANIUN STEEL 45 DEGREE LONG RADIUS ELBOW / SUPER DUPLEX STEEL 45 DEGREE LONG RADIUS ELBOW / INCOLOY STEEL 45 DEGREE LONG RADIUS ELBOW / ALLOY 20 45 DEGREE LONG RADIUS ELBOW / 254 SMO 45 DEGREE LONG RADIUS ELBOW/ COPPER NICKEL STEEL 45 DEGREE LONG RADIUS ELBOW / BUTTWELD 45 DEGREE LR ELBOW
ANSI/ASME B16.9 45° Long Radius Elbow Exporter in India

What is 45 Degree Long Radius Elbow?

Fittings that change direction in a piping system are called elbows. The directional change is given in degree such as 45 or 90. 45 degree Long Radius elbow is same as LR45 except for the measurement between end of elbow to center line is 1 x NPS.

45 Degree Long Radius Elbow Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

45 Degree Long Radius Elbow Materials and Grade

Stainless Steel 45 degree Long Radius Elbow:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 45 degree Long Radius Elbow:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy 45 degree Long Radius Elbow:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy steel 45 degree Long Radius Elbow:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of 45 degree Long radius elbow in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of ANSI/ASME B16.9 45° Long Radius Elbow. We keep intensive stock of Long radius 45 degree elbow to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of both seamless and welded 45 deg Long radius elbow. We have over 4 decades of experience in manufacturing of ASME B16.9 Butt weld 45 degree Long Radius Elbow using high quality of raw materials and using latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

45 Degree Long Radius Elbow Price List

Following is 45 Degree Long Radius Elbow price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
45 Degree Long Radius Elbow $1.00-$5.00 USD/Piece
stainless steel 45 degree Long Radius Elbow $1.00-$30.00 USD/Piece
Steel Elbow, Long Radius, 45 Degree, Pipe Fittings, Butt-Weld $2.50-$12.00 USD/Kilogram
asme b16.28 long radius SS pipe elbow 45 degree dimensions $1.00-$10.00 USD/Piece
45 degree Long Radius(LR r=1.5d) Elbow $0.50-$99.00 USD/Piece
Sanitary grade 45 Degree Elbow $1.00-$10.00 USD/Piece
45 degree long radius pipe Welding elbow for Joining $1.00-$100.00 USD/Piece
45 Degree Carbon Steel Long Radius Elbow $2.40-$2.50 USD/Piece
45 degree high pressure long radius elbow $40.00-$50.00 USD/Piece
Long Radius 45 degree Elbow ANSI B16.9 $1.00-$25.00 USD/Piece
ASME B16.9 DN 500 SCH STD CS 45 Deg. LR elbow $5.00-$999.00 USD/Piece
45 degree long radius seamless carbon steel elbow $4.00-$10.00 USD/Piece
SS 45 degree Long Butt radius welding Elbow $6.69-$16.38 USD/Piece
Galvanized Steel 45 Degree Long Radius Elbow $0.50-$100.00 USD/Piece
45 degree Elbow $1.00-$1000.00 USD/Piece
dn80 3″ sch80 45 degree long radius smls elbow $0.50-$1.00 USD/Kilogram
Butt weld pipe fitting Long Radius Elbow 45 degree $1.00-$38.00 USD/Piece
copper pipe fitting 45 degree long radius elbow $0.50-$3.00 USD/Piece

Reference:alibaba

45 Degree Long Radius Elbow Dimensions:

Butt weld 45 degree Long Radius Elbow Dimensions

NPS O.D.
D
90 degrees
Long Radius
Center-to-End
A
45 degrees
Long Radius
Center-to-End
B
90 degrees
3D
Center-to-End
A
45 degrees
3D
Center-to-End
B
1/2 21.3 38 16
3/4 26.7 38 19 57 24
1 33.4 38 22 76 31
42.2 48 25 95 39
48.3 57 29 114 47
2 60.3 76 35 152 63
73 95 44 190 79
3 88.9 114 51 229 95
101.6 133 57 267 111
4 114.3 152 64 305 127
5 141.3 190 79 381 157
6 168.3 229 95 457 189
8 219.1 305 127 610 252
10 273 381 159 762 316
12 323.8 457 190 914 378
14 355.6 533 222 1067 441
16 406.4 610 254 1219 505
18 457 686 286 1372 568
20 508 762 318 1524 632
22 559 838 343 1676 694
24 610 914 381 1829 757
26 660 991 406 1981 821
28 711 1067 438 2134 883
30 762 1143 470 2286 964
32 813 1219 502 2438 1010
34 864 1295 533 2591 1073
36 914 1372 565 2743 1135
38 965 1448 600 2896 1200
40 1016 1524 632 3048 1264
42 1067 1600 660 3200 1326
44 1118 1676 695 3353 1389
46 1168 1753 727 3505 1453
48 1219 1829 759 3658 1516

45 Degree Long Radius Elbow Dimensional Tolerance

DIMENSIONAL TOLERANCES – ELBOWS
For all fittings Elbows 90/45 deg 180° Returns
Nominal Pipe Size (NPS) Outside Ø
at Bevel
Inside Ø
at End
Wall Thickness
t / t1
Center to End Dim. A-B-C-M Center to Center Dim.
O
Back to Face Dim.
K
Align- ment of Ends
U
1/2 a 2 1/2 1 0,8 Not 2 7 7 1
3 a 3 1/2 1 1,6 less 2 7 7 1
4 +2 -1 1,6 than 2 7 7 1
5 a 6 +3 -1 1,6 87,50% 2 7 7 1
8 2 1,6 of nominal 2 7 7 1
10 +4 -3 3,2 tickness 2 7 7 2
12 a 18 +4 -3 3,2 3 10 7 2
20 a 24 +6 -5 4,8 3 10 7 2
26 a 30 +7 -5 4,8 3 ….. ….. …..
32 a 48 +7 -5 4,8 5 ….. ….. …..

45 Degree Long Radius Elbow Angularity Tolerances

Angularity Tolerances
ND Max off angle Max off plane
Q P
1/2 a 4 1 2
5 a 8 2 4
10 a 12 3 5
14 a 16 3 7
18 a 24 4 10
26 a 30 5 10
32 a 42 5 13
44 a 48 5 20
