Buttweld ASME B16.9 1D Elbow Manufacturer


Leading ANSI/ASME B16.9 1D Elbow Manufacturers in India and Authoritative Stainless Steel 1D Elbows Supplier in India and Overseas.

ANSI/ASME B16.9 1D Elbow Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 1D Elbow, ss 1d elbows, 1d 90 elbow, nickel alloy 1d elbow provided at affordable prices in India.

We keep the largest stock of asme b16 9 1d elbow, 1d 90 elbow, and also manufacturing high-quality stainless steel 1d elbow, butt weld 1d elbow, carbon steel 1d elbow, nickel alloy 1d elbow, alloy steel 1d elbow, monel 1d elbow, inconel 1d elbow in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 1D ELBOW / 1D 90 ELBOW / STAINLESS STEEL 1D ELBOW / DUPLEX STEEL 1D ELBOW / CARBON STEEL 1D ELBOW / ALLOY STEEL 1D ELBOW / HASTELLOY STEEL 1D ELBOW / MONEL STEEL 1D ELBOW / INCONEL STEEL 1D ELBOW / TITANIUN STEEL 1D ELBOW / SUPER DUPLEX STEEL 1D ELBOW / INCOLOY STEEL 1D ELBOW / ALLOY 20 1D ELBOW / 254 SMO 1D ELBOW/ COPPER NICKEL STEEL 1D ELBOW / BUTTWELD 1D ELBOW
ANSI/ASME B16.9 1D Elbow Exporter in India

ANSI/ASME B16.9 1D Elbow Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 1D Elbow Materials and Grade

Stainless Steel 1D Elbow:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 1D Elbow:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy 1D Elbow:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel 1D Elbow:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 1D Elbow in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of ANSI/ASME B16.9 1D Elbow. We keep intensive stock of 1d 90 elbow to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of both seamless and welded ANSI/ASME B16.9 1D Elbow. We have over 4 decades of experience in manufacturing of ASME B16 9 1D Elbows using high quality of raw materials and using latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 1D Elbow Price List

Following is ANSI/ASME B16.9 1D Elbow price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
1d seamless carbon steel elbow a234 $1.00-$200.00 USD/Piece
seamless 90 degree radius r=1d pipe elbow $0.50-$1.00 USD/Piece
1D Bend Elbow $1.00-$1000.00 USD/Unit
SS BW SR SCH 40 Elbow 90 1D 6″ ASME B16.9 $10.00-$100.00 USD/Piece
30,45,60,90,180 degree 1D steel pipe elbow $0.10-$110.00 USD/Piece
carbon steel 1d elbow $1.00-$100.00 USD/Piece
1d stainless steel elbow $1.50-$150.00 USD/Piece
sanitary 1D welding elbow $1.00-$20.00 USD/Piece
ASME B16.9 LR 90 degree elbow 1D $5.00-$50.00 USD/Piece
GOST1735-2001,GOST30753-1,r-1d elbow $1.00-$500.00 USD/Ton
1.0 D 90 deg sch 40 Butt Welding Elbow $0.10-$99.00 USD/Piece
1D nickel alloy Incoloy 800HT elbow $100.00 USD/Pieces
bw short radius r=1d degree elbow $15.00-$954.00 USD/Piece
welding 90deg elbow. R=1D ASME/ANSI B16.28 $1000.00-$10000.00 USD/Piece
ASTME B16.9 r=1D titanium metal elbow $4.90-$30.00 USD/Piece
76mm or 3 inch Stainless 1D exhaust tight bends $6.00-$7.00 USD/Piece
1D Bend Elbow $1.00-$1000.00 USD/Ton
return bend R=1D SR 4″ XS 180degree elbow $6.10-$7.60 USD/Kilogram

Reference:alibaba

Buttweld ANSI/ASME B16.9 1D Elbow Dimensions:

Size   Wall Thickness Radius Approx. Weight (kg)
DN OD s a
inch mm mm mm mm mm 45° 90°
Seamless
1 25 30 1.5 30 12 0.03 0.05
32 38 1.5 32.5 14 0.03 0.08
40 44.5 1.5 40 17 0.06 0.14
2 50 57 1.5 52.5 22 0.10 0.20
65 76 2 70 29 0.23 0.46
3 80 89 2 82.5 34 0.32 0.64
4 100 108 2.5 100 41 0.58 1.16
5 125 133 2.5 125 52 0.90 1.80
6 150 159 2.5 150 62 1.30 2.60
7 175 194 3 180 75 1.90 3.80
8 200 219 3 210 87 3.00 6.00
10 250 267 3 255 106 4.44 8.88
12 300 324 4 305 126 8.55 17.10
14 350 368 4 352.5 146 11.30 22.60
16 400 419 4 400 166 16.40 32.80
18 450 457 4.5 457 189 20.45 40.90
20 500 508 5 508 210 28.10 56.20
24 600 610 5 610 253 40.50 81.00
28 700 711 6 711 295 66.00 132.00
32 800 813 6 813 337 86.50 173.00
36 900 914 8 914 379 145.50 291.00

ANSI/ASME B16.9 1D Elbow Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 1d elbow and supplying to various core industries like

Chemicals Fertilizers Industries

Chemicals Fertilizers Industries
Heat Exchanger

Heat Exchanger
Instrumentation

Instrumentation
Nuclear Thermal Industries

Nuclear Thermal Industries
Oil Gas Industries

Oil Gas Industries
Pharmacy Surgical Industries

Pharmacy Surgical Industries
Refineries Petrochemicals

Refineries Petrochemicals
Water Gas Piping Systems

Water Gas Piping Systems
