Buttweld ASME B16.9 Collar Manufacturer


Leading ANSI/ASME B16.9 Butt weld Collar Manufacturers and Authoritative Buttweld Collar Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Collar Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld collar, we are providing high-quality SS pipe collar at best price in India.

We keep the largest stock of stainless steel collar, carbon steel collar, nickel alloy collar, alloy steel collar, monel collar in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD COLLAR / STAINLESS STEEL BUTT WELD COLLAR / DUPLEX STEEL BUTT WELD COLLAR / CARBON STEEL BUTT WELD COLLAR / ALLOY STEEL BUTT WELD COLLAR / HASTELLOY STEEL BUTT WELD COLLAR / MONEL STEEL BUTT WELD COLLAR / INCONEL STEEL BUTT WELD COLLAR / TITANIUN STEEL BUTT WELD COLLAR / SUPER DUPLEX STEEL BUTT WELD COLLAR / INCOLOY STEEL BUTT WELD COLLAR / ALLOY 20 BUTT WELD COLLAR / 254 SMO BUTT WELD COLLAR/ COPPER NICKEL STEEL BUTT WELD COLLAR
ANSI/ASME B16.9 Butt weld Collar Exporter in India

ANSI/ASME B16.9 Butt weld Collar Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Collar Materials and Grade

Stainless Steel Butt weld Collar:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Collar:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Collar:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Collar:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Collar in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Buttweld Collar. We keep intensive stock of Collar Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Collar. We have over 4 decades of experience in manufacturing of both Seamless & Welded Collar Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, pipe cap or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Collar Price List

Following is ANSI/ASME B16.9 Butt weld Collar price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Buttweld Collar Pipe Fitting $1.00-$5.00 USD/Piece
Carbon Steel Collar Pipe Fittings $1.00-$20.00 USD/Piece
Stainless Steel Buttweld Collar Pipe Fitting $1.00-$5.00 USD/Piece
Alloy Steel Buttweld Collar Pipe Fitting $1.00-$5.00 USD/Piece
Corrosion resistant SS pipe collar $0.10-$19.90 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Collar Dimensions:

COLLARS for ANSI 150 flanges
inches ND mm Diameter
of lap
Height Radius of
fillet
D G h R
1/2 15 21,34 34,92 5 3
3/4 20 26,67 42,86 6 3
1 25 33,40 50,80 8 3
1 1/4 32 42,16 63,50 8 5
1 1/2 40 48,26 73,00 10 6
2 50 60,32 92,10 10 8
2 1/2 65 73,02 104,80 12 8
3 80 88,90 127,00 12 9
3 1/2    90 101,60 139,70 12 9
4 100 114,30 157,20 14 11
5 125 141,30 185,70 16 11
6 150 168,27 215,90 16 12
8 200 219,07 269,80 18 12
10 250 273,05 323,80 20 12
12 300 323,85 381,00 20 12
14 350 355,60 412,70 25 12
16 400 406,40 469,90 25 12
18 450 457,20 533,40 25 12
20 500 508,00 584,20 25 12
22 550 558,80 641,30 25 12
24 600 609,60 692,10 25 12
Dimension in mm.
The values of radius "R" and height "h" are indicative

Butt weld ASME B16.9 UNI and DIN flanges:

COLLARS for UNI and DIN flanges
inches ND mm Diameter
of lap G
Height Radius of
fillet
D PN
2,5-6
PN
10
PN
16
h R
1/2 15 21,34 40 45 45 5 2
3/4 20 26,67 50 58 58 8 2
1 25 33,40 60 68 68 8 3
1 1/4 32 42,16 70 78 78 8 3
1 1/2 40 48,26 80 88 88 10 3
2 50 60,32 90 102 102 10 4
2 1/2 65 73,02 110 122 122 12 4
3 80 88,90 128 138 138 12 5
4 100 114,30 148 158 158 14 5
5 125 141,30 178 188 188 14 5
5 125 141,30 178 188 188 14 5
6 150 168,27 202 212 212 16 6
8 200 219,07 258 268 268 18 6
10 250 273,05 312 320 320 20 6
12 300 323,85 365 370 378 20 6
14 350 355,60 415 430 438 25 8
16 400 406,40 465 482 490 25 8
18 450 457,20 520 532 550 25 8
20 500 508,00 570 585 610 25 8
Dimension in mm.
The values of radius "R" and height "h" are indicative

ANSI/ASME B16.9 Butt weld Collar Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld Collar and supplying to various core industries like

Chemicals Fertilizers Industries

Chemicals Fertilizers Industries
Heat Exchanger

Heat Exchanger
Instrumentation

Instrumentation
Nuclear Thermal Industries

Nuclear Thermal Industries
Oil Gas Industries

Oil Gas Industries
Pharmacy Surgical Industries

Pharmacy Surgical Industries
Refineries Petrochemicals

Refineries Petrochemicals
Water Gas Piping Systems

Water Gas Piping Systems
