Butt weld ASME B16.9 Lap Joint Stub End Manufacturer


Leading ANSI/ASME B16.9 Butt weld Lap Joint Stub End Manufacturers and Authoritative SS Lap Joint Stub End Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Lap Joint Stub End Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld lap joint with stub end, we are providing high-quality mss lap joint stub ends at best price in India.

We keep the largest stock of 12 lap joint stub end, 6 lap joint stub end, stainless steel lap joint stub end, carbon steel lap joint stub end, nickel alloy lap joint stub end, alloy steel lap joint stub end, monel lap joint stub end, copper lap joint stub end in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD LAP JOINT STUB END / STAINLESS STEEL BUTT WELD LAP JOINT STUB END / DUPLEX STEEL BUTT WELD LAP JOINT STUB END / CARBON STEEL BUTT WELD LAP JOINT STUB END / ALLOY STEEL BUTT WELD LAP JOINT STUB END / HASTELLOY STEEL BUTT WELD LAP JOINT STUB END / MONEL STEEL BUTT WELD LAP JOINT STUB END / INCONEL STEEL BUTT WELD LAP JOINT STUB END / TITANIUN STEEL BUTT WELD LAP JOINT STUB END / SUPER DUPLEX STEEL BUTT WELD LAP JOINT STUB END / INCOLOY STEEL BUTT WELD LAP JOINT STUB END / ALLOY 20 BUTT WELD LAP JOINT STUB END / 254 SMO BUTT WELD LAP JOINT STUB END/ COPPER NICKEL STEEL BUTT WELD LAP JOINT STUB END
ANSI/ASME B16.9 Butt weld Lap Joint Stub End Exporter in India

ANSI/ASME B16.9 Butt weld Lap Joint Stub End Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Lap Joint Stub End Materials and Grade

Stainless Steel Butt weld Lap Joint Stub End:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Lap Joint Stub End:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Lap Joint Stub End:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Lap Joint Stub End:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Lap Joint Stub End in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Lap Joint Stub End. We keep intensive stock of MSS Lap Joint Stub End Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Lap Joint Stub End. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Lap Joint Stub End Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, lap joint stub end or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Lap Joint Stub End Price List

Following is ANSI/ASME B16.9 Butt weld Lap Joint Stub End price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Butt welded Fitting Pipe Lap Joint Stub End $5.00-$10.00 USD/Piece
SS Lap Joint Stub End Butt Weld Pipe Fitting $1.00-$10.00 USD/Piece
copper nickel 90/10 stub end lap joint $1.00-$100.00 USD/Piece
ANSI B16.9 butt welded lap joint stub end $10.00-$100.00 USD/Piece
mss_sp_43 butt weld lap joint stub end $4.00-$35.00 USD/Piece
Butt Welding Seamless lap joint Stub End $3.50-$35.00 USD/Piece
B16.9 welding Gr5 Lap Joint Titanium Stub End $5.00-$70.00 USD/Piece
Stainless steel lap joint flange stub ends $1.00-$99.00 USD/Piece
ASTM A403 WP304L Lap Joint Stub End $1.00-$10000.00 USD/Piece
SS 304 butt welded Stub End of Flange $1.00-$10.00 USD/Piece
sch40 lap joint flange stub ends $0.50-$120.00 USD/Piece
Brass long lap joint flange seamless stub ends $0.10-$99.00 USD/Piece
seamless jis standard SS lap joint stub end $6.10-$7.60 USD/Kilogram

Reference:alibaba

ASME B16.9 Butt weld Lap Joint Stub End Dimensions:

Nominal Pipe Size Outside diameter
of barrel
Length (F) Radius (R) Diameter (G)
Minimum Maximum Long
Pattern
Short
Pattern
1/2" 20.5 22.8 76 51 3 35
3/4" 25.9 28.1 76 51 3 43
1" 32.6 35.0 102 51 3 51
1 1/4" 41.4 43.6 102 51 5 64
1 1/2" 47.5 49.9 102 51 6 74
2" 59.5 62.4 152 64 8 92
2 1/2" 72.2 75.3 152 64 8 105
3" 88.1 91.3 152 64 10 127
3 1/2" 100.8 104.0 152 76 10 140
4" 113.5 116.7 152 76 11 157
5" 140.5 144.3 203 76 11 186
6" 167.5 171.3 203 89 13 216
8" 218.3 222.1 203 102 13 270
10" 272.3 277.2 254 127 13 324
12" 323.1 328.0 254 152 13 381
14" 354.8 359.9 305 152 13 413
16" 405.6 411.0 305 152 13 470
18" 456.0 462.0 305 152 13 533
20" 507.0 514.0 305 152 13 584
22" 558.0 565.0 305 152 13 641
24" 609.0 616.0 305 152 13 692

Butt weld Lap Joint Stub End – ANSI B16.9 Tolerances:

DIMENSIONAL TOLERANCES – LAP JOINT STUB ENDS
For all fittings Stub Ends
Nominal Pipe Size (NPS) Outside Ø at Bevel Indide Ø at End Wall Thickness
t / t1
O.D. of Lap G Fillet Radius of Lap – R Overall Length. – F
1/2 a 2 1/2 1 0,8 Not +0 -1 +0 -1 2
3 a 3 1/2 1 1,6 less +0 -1 +0 -1 2
4 +2 -1 1,6 than +0 -1 +0 -2 2
5 a 6 +3 -1 1,6 87,50% +0 -1 +0 -2 2
8 2 1,6 of nominal +0 -1 +0 -2 2
10 +4 -3 3,2 tickness +0 -2 +0 -2 2
12 to 18 +4 -3 3,2 +0 -2 +0 -2 3
20 a 24 +6 -5 4,8 +0 -2 +0 -2 3
26 a 30 +7 -5 4,8
32 a 48 +7 -5 4,8

ANSI/ASME B16.9 Butt weld Lap Joint Stub End Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld Lap Joint Stub End and supplying to various core industries like

Chemicals Fertilizers Industries

Chemicals Fertilizers Industries
Heat Exchanger

Heat Exchanger
Instrumentation

Instrumentation
Nuclear Thermal Industries

Nuclear Thermal Industries
Oil Gas Industries

Oil Gas Industries
Pharmacy Surgical Industries

Pharmacy Surgical Industries
Refineries Petrochemicals

Refineries Petrochemicals
Water Gas Piping Systems

Water Gas Piping Systems
