Buttweld ASME B16.9 Pipe Cap Manufacturer


Leading ANSI/ASME B16.9 Butt weld Pipe Cap Manufacturers and Authoritative Buttweld Pipe Caps Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Pipe Cap Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld pipe cap, we are providing high-quality SS pipe cap at best price in India.

We keep the largest stock of pipe cap stainless steel, buttweld pipe caps, pipe cap asme b16.9, pipe cap carbon steel, pipe cap copper, pipe cap brass, pipe cap aluminum, pipe cap fitting in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD PIPE CAP / STAINLESS STEEL BUTT WELD PIPE CAP / DUPLEX STEEL BUTT WELD PIPE CAP / CARBON STEEL BUTT WELD PIPE CAP / ALLOY STEEL BUTT WELD PIPE CAP / HASTELLOY STEEL BUTT WELD PIPE CAP / MONEL STEEL BUTT WELD PIPE CAP / INCONEL STEEL BUTT WELD PIPE CAP / TITANIUN STEEL BUTT WELD PIPE CAP / SUPER DUPLEX STEEL BUTT WELD PIPE CAP / INCOLOY STEEL BUTT WELD PIPE CAP / ALLOY 20 BUTT WELD PIPE CAP / 254 SMO BUTT WELD PIPE CAP/ COPPER NICKEL STEEL BUTT WELD PIPE CAP
ANSI/ASME B16.9 Butt weld Pipe Cap Exporter in India

ANSI/ASME B16.9 Butt weld Pipe Cap Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Pipe Cap Materials and Grade

Stainless Steel Butt weld Pipe Cap:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Pipe Cap:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Pipe Cap:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Pipe Cap:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Pipe Cap in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Buttweld Pipe Cap. We keep intensive stock of Pipe Cap Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Pipe Cap. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Cap Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, pipe cap or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Pipe Cap Price List

Following is ANSI/ASME B16.9 Butt weld Pipe Cap price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
B16.9 sch40 SS pipe fitting butt weld end cap $10.00-$50.00 USD/Piece
butt welding steel pipe end bw cap $0.20-$1000.00 USD/Piece
butt weld carbon steel pipe cap $10.00-$100.00 USD/Piece
Butt Welded 36″ Steel Pipe End Cap $0.90-$500.00 USD/Piece
Stainless steel cap pipe $10.00-$12.00 USD/Piece
Butt welded pipe cap $1.00-$200.00 USD/Piece
ansi b16.9 butt welded alloy steel blind pipe cap $0.50-$10.00 USD/Piece
4 inch sch40 butt welded pipe cap $0.50-$20.00 USD/Piece
black butt weld carbon steel pipe fitting end cap $32.00-$91.00 USD/Piece
butt welded carbon steel elliptical caps $1.00-$13.00 USD/Piece
Butt Welded 30 Inch Pipe Cap $10.00-$100.00 USD/Piece
butt welded 24″ pipe end cap $3.80-$15.00 USD/Piece
ASTM DN 150 Sch 80 CS Butt Welded Pipe Cap $72.00-$75.00 USD/Piece
aluminium alloy butt welded pipe cap $700.00-$800.00 USD/Piece
Large Diameter Butt Welded Pipe Caps $0.50-$55.00 USD/Piece
Seamless Butt Weld 2 inch SS pipe fitting cap $0.50-$189.00 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Pipe Cap Dimensions:

Nominal Pipe Size Outside diameter
at bevel
Length (E) Limit wall thickness
1/2" 21.3 25 4.57
3/4" 26.7 25 3.81
1" 33.4 38 4.57
1 1/4" 42.2 38 4.83
1 1/2" 48.3 38 5.08
2" 60.3 38 5.59
2 1/2" 73.0 38 7.11
3" 88.9 51 7.62
3 1/2" 101.6 64 8.13
4" 114.3 64 8.64
5" 141.3 76 9.65
6" 168.3 89 10.92
8" 219.1 102 12.70
10" 273.0 127 12.70
12" 323.8 152 12.70
14" 355.6 165 12.70
16" 406.4 178 12.70
18" 457.0 203 12.70
20" 508.0 229 12.70
22" 559.0 254 12.70
24" 610.0 267 12.70

Note: The dimensions are in millimeters
Source : ASME B16.9 – 2007

Butt weld ASME B16.9 Pipe Cap Tolerances:

DIMENSIONAL TOLERANCES – CAPS
For all fittings Caps
Nominal Pipe Size (NPS) Outside Ø at Bevel Inside Ø at End Wall Thickness
t / t1
Overall Length E
1/2 a 2 1/2 1 0,8 Not 4
3 a 3 1/2 1 1,6 less 4
4 +2 -1 1,6 than 4
5 a 6 +3 -1 1,6 87,50% 7
8 2 1,6 of nominal 7
10 +4 -3 3,2 tickness 7
12 a 18 +4 -3 3,2   7
20 a 24 +6 -5 4,8   7
26 a 30 +7 -5 4,8   10
32 a 48 +7 -5 4,8   10

ANSI/ASME B16.9 Butt weld Pipe Cap Application
