Butt weld ASME B16.9 Reducers Manufacturer


Leading ANSI/ASME B16.9 Butt weld Reducers Manufacturers and Authoritative SS Reducers Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Reducers Manufacturers in India

As a leading manufacturer, stockist, and exporters of butt weld reducers we are providing high-quality buttweld reducers pipe fitting at best price in India.

We keep the largest stock of stainless steel reducers, carbon steel reducers, nickel alloy reducers, alloy steel reducers, monel reducers, copper reducers, reducers fitting in all dimension.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD REDUCERS / STAINLESS STEEL BUTT WELD REDUCERS / DUPLEX STEEL BUTT WELD REDUCERS / CARBON STEEL BUTT WELD REDUCERS / ALLOY STEEL BUTT WELD REDUCERS / HASTELLOY STEEL BUTT WELD REDUCERS / MONEL STEEL BUTT WELD REDUCERS / INCONEL STEEL BUTT WELD REDUCERS / TITANIUN STEEL BUTT WELD REDUCERS / SUPER DUPLEX STEEL BUTT WELD REDUCERS / INCOLOY STEEL BUTT WELD REDUCERS / ALLOY 20 BUTT WELD REDUCERS / 254 SMO BUTT WELD REDUCERS/ COPPER NICKEL STEEL BUTT WELD REDUCERS
ANSI/ASME B16.9 Butt weld Reducers Exporter in India

ANSI/ASME B16.9 Butt weld Reducers Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Reducers Materials and Grade

Stainless Steel Butt weld Reducers:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Reducers:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Reducers:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Reducers:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Reducers in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Reducers. We keep intensive stock of Reducers Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI Reducers. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Reducers Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Reducers Price List

Following is ANSI/ASME B16.9 Butt weld Reducers price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
stainless steel butt welding reducer $0.40-$40.00 USD/Piece
Butt Weld Pipe Fittings Reducer $10.00-$50.00 USD/Piece
Butt Welding Pipe Fittings Reducer $1.00-$100.00 USD/Piece
Carbon Steel butt welded reducer $1.00-$99.00 USD/Piece
ss316 butt welded conc reducer $3.00-$320.00 USD/Piece
ANSI B16.9 Butt Welded Stainless steel reducer $1.00-$100.00 USD/Piece
carbon steel reducer dn50 dn65 $0.50-$25.00 USD/Piece
48.3mm x 42mm long reducer $132.00 USD/Piece
Titanium ASME B16.9 butt Welded Reducer $1.00-$50.00 USD/Piece
b16.9 butt weld 8 inch to 6 inch reducer $3.36-$5.67 USD/Piece
Asme b 16.5 3 inch to 2 inch butt welding reducer $12.00-$13.00 USD/Piece
reducer butt welded fitting $0.50-$7.30 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Reducers Dimensions:

REDUCERS
inches mm D d H
3/4 x 3/4 20 x 15 26,67 21,34 38,10
3/4 x 3/8 20 x 10 26,67 17,14 38,10
1 x 3/4 25 x 20 33,40 26,67 50,80
1 x 1/2 25 x 15 33,40 21,34 50,80
1 1/4 x 1 32 x 25 42,16 33,40 50,80
1 1/4 x 3/4 32 x 20 42,16 26,67 50,80
1 1/4 x 1/2 32 x 15 42,16 21,34 50,80
1 1/2 x 1 1/4 40 x 32 48,26 42,16 63,50
1 1/2 x 1 40 x 25 48,26 33,40 63,50
1 1/2 x 3/4 40 x 20 48,26 26,67 63,50
1 1/2 x 1/2 40 x 15 48,26 21,34 63,50
2 x 1 1/2 50 x 40 60,32 48,26 76,20
2 x 1 1/4 50 x 32 60,32 42,16 76,20
2 x 1 50 x 25 60,32 33,40 76,20
2 x 3/4 50 x 20 60,32 26,67 76,20
2 1/2 x 2 65 x 50 73,02 60,32 88,90
2 1/2 x 1 1/2 65 x 40 73,02 48,26 88,90
2 1/2 x 1 1/4 65 x 32 73,02 42,16 88,90
2 1/2 x1 65 x 25 73,02 33,40 88,90
3 x 2 1/2 80 x 65 88,90 73,02 88,90
3 x 2 80 x 50 88,90 60,32 88,90
3 x 1 1/2 80 x 40 88,90 48,26 88,90
3 x 1 1/4 80 x 32 88,90 42,16 88,90
3 1/2 x 3 90 x 80 101,60 88,90 101.60
3 1/2 x 2 1/2 90 x 65 101,60 73,02 101.60
3 1/2 x 2 90 x 50 101,60 60,32 101.60
3 1/2 x 1 1/2 90 x 40 101,60 48,26 101.60
3 1/2 x 1 1/4 90 x 32 101,60 42,16 101.60
4 x 3 1/2 100 x 90 114,30 73,02 101.60
4 x 3 100 x 80 114,30 88,90 101.60
4 x 2 1/2 100 x 65 114,30 73,02 101.60
4 x 2 100 x 50 114,30 60,32 101.60
4 x 1 1/2 100 x 40 114,30 48,26 101.60
5 x 4 125 x 100 141,30 114,30 127,00
5 x 3 1/2 125 x 90 141,30 101,60 127,00
5 x 3 125 x 80 141,30 88,90 127,00
5 x 2 1/2 125 x 65 141,30 73,02 127,00
5 x 2 125 x 50 141,30 60,32 127,00
6 x 5 150 x 125 168,27 141,30 139,7
6 x 4 150 x 100 168,27 114,30 139,7
6 x 1/2 150 x 90 168,27 101,60 139,7
6 x 3 150 x 80 168,27 88,90 139,7
6 x 1/2 150 x 65 168,27 73,02 139,7
8 x 6 200 x 150 219,07 168,27 152,4
8 x 5 200 x 125 219,07 141,30 152,4
8 x 4 200 x 100 219,07 114,30 152,4
8 x 3 1/2 200 x 90 219,07 101,60 152,4
10 x 8 250 x 200 273,05 219,07 177,8
10 x 6 250 x 150 273,05 168,27 177,8
10 x 5 250 x 125 273,05 141,30 177,8
10 x 4 250 x 100 273,05 114,30 177,8
12 x 10 300 x 250 323,85 273,05 203,2
12 x 8 300 x 200 323,85 219,07 203,2
12 x 6 300 x 150 323,85 168,27 203,2
12 x 5 300 x 125 323,85 141,30 203,2
14 x 12 350 x 300 355,60 323,85 330,2
14 x 10 350 x 250 355,60 273,05 330,2
14 x 8 350 x 200 355,60 219,07 330,2
14 x 6 350 x 150 355,60 168,27 330,2
16 x 14 400 x 350 406,40 355,60 355,6
16 x 12 400 x 300 406,40 323,85 355,6
16 x 10 400 x 250 406,40 273,05 355,6
16 x 8 400 x 200 406,40 219,07 355,6
18 x 16 450 x 400 457,20 406,40 381,0
18 x 14 450 x 350 457,20 355,60 381,0
18 x 12 450 x 300 457,20 323,85 381,0
18 x 10 450 x 250 457,20 273,05 381,0
20 x 18 500 x 450 508,00 457,20 508,0
20 x 16 500 x 400 508,00 406,40 508,0
20 x 14 500 x 350 508,00 355,60 508,0
20 x 12 500 x 300 508,00 323,85 508,0
22 x 20 550 x 500 558,80 508,00 508,0
22 x 18 550 x 450 558,80 457,20 508,0
22 x 16 550 x 400 558,80 406,40 508,0
22 x 14 550 x 350 558,80 355,60 508,0
24 x 22 600 x 550 609,6 558,80 508,0
24 x 20 600 x 500 609,6 508,00 508,0
24 x 18 600 x 450 609,6 457,20 508,0
24 x 16 600 x 400 609,6 406,40 508,0
Dimension in mm.

ANSI/ASME B16.9 Butt weld Reducers Dimensions tolerances

DIMENSIONAL TOLERANCES – REDUCERS
  Reducers
Nominal Pipe Size (NPS) Outside Ø at Bevel Inside Ø at End Wall Thickness
t / t1
Overall Length
H
1/2 a 2 1/2 1 0,8 Not 2
3 a 3 1/2 1 1,6 less 2
4 +2 -1 1,6 than 2
5 a 6 +3 -1 1,6 87,50% 2
8 2 1,6 of nominal 2
10 +4 -3 3,2 tickness 2
12 a 18 +4 -3 3,2 3
20 a 24 +6 -5 4,8   3
26 a 30 +7 -5 4,8   3
32 a 48 +7 -5 4,8   5

ANSI/ASME B16.9 Butt weld Reducers Weights

WEIGHTS OF FITTINGS
NPS
inches
REDUCERS*
Sch.
5S
Sch.
10S
Sch.
40S
Sch.
80S
1/2 0.04 0.04 0.05 0.06
3/4 0.10 0.10 0.14 0.18
1 0.12 0.12 0.16 0.22
1 1/4 0.18 0.18 0.22 0.27
1 1/2 0.21 0.21 0.28 0.33
2 0.30 0.30 0.40 0.55
2 1/2 0.45 0.45 0.80 1.00
3 0.50 0.50 0.90 1.20
4 0.80 0.80 1.50 2.20
5 1.40 1.40 2.70 3.70
6 2.00 2.00 4.00 5.80
8 3.10 3.10 6.90 9.30
10 4.80 4.80 10.5 14.5
12 9.00 9.00 19.0 25.0
14 15.5 15.5 31.0 41.5
16 19.0 19.0 38.0 50.5
18 23.0 23.0 46.0 61.5
20 34.0 34.0 58.5 78.0
24 50.0 50.0 75.0 100
Approximate weights in kg, density 8 kg/dm3
Weights are referred to the reduction with the first smaller diameter

ANSI/ASME B16.9 Butt weld Reducers Application
