180 Degree Return Bends Manufacturer


Leading ANSI/ASME B16.9 Seamless Buttwelding 180 Degree Return Bends Manufacturers and Authoritative SS 180 Degree Return Bends Pipe Supplier in India and Overseas.

ANSI/ASME B16.9 180 Degree Return Bends Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 Seamless Buttwelding 180° Return Bends, 180 degree copper return bend, 22mm copper 180-degree return bend, 15mm copper 180 degree return bends are provided in all dimensions and at an affordable price in India.

We keep the largest stock of Stainless Steel Seamless Butt weld 180° Returns, Carbon Steel Seamless Butt weld 180° Returns, Nickel Alloy Seamless Butt weld 180° Returns, Alloy steel Seamless Butt weld 180° Returns, Monel Seamless Butt weld 180° Returns, Inconel Seamless Butt weld 180° Returns.

Contact Us

WE ARE MANUFACTURING 180 DEGREE RETURN BENDS / STAINLESS STEEL 180 DEGREE RETURN BENDS / DUPLEX STEEL 180 DEGREE RETURN BENDS / CARBON STEEL 180 DEGREE RETURN BENDS / ALLOY STEEL 180 DEGREE RETURN BENDS / HASTELLOY STEEL 180 DEGREE RETURN BENDS / MONEL STEEL 180 DEGREE RETURN BENDS / INCONEL STEEL 180 DEGREE RETURN BENDS / TITANIUN STEEL 180 DEGREE RETURN BENDS / SUPER DUPLEX STEEL 180 DEGREE RETURN BENDS / INCOLOY STEEL 180 DEGREE RETURN BENDS / ALLOY 20 180 DEGREE RETURN BENDS / 254 SMO 180 DEGREE RETURN BENDS/ COPPER NICKEL STEEL 180 DEGREE RETURN BENDS
ANSI/ASME B16.9 180 Degree Return Bends Exporter in India

ANSI/ASME B16.9 180 Degree Return Bends Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 180 Degree Return Bends Materials and Grade

Stainless Steel ANSI/ASME B16.9 180 Degree Return Bends:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel ANSI/ASME B16.9 180 Degree Return Bends:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy ANSI/ASME B16.9 180 Degree Return Bends:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel ANSI/ASME B16.9 180 Degree Return Bends:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 180 Degree Return Bends in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of 180 degree return bend pipe. We keep intensive stock of SS 180 degree return bend pipe to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of 180 degree copper return bend. We have over 4 decades of experience in manufacturing of seamless buttwelding 180° return bends using high quality of raw materials and latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 180 Degree Return Bends Price List

Following is ANSI/ASME B16.9 180 Degree Return Bends price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
180 degree return bend $0.50-$100.00 USD/Piece
copper fittings 7/8 180 degree return bends $10.00-$100.00 USD/Piece
180 degree carbon steel a106 gr.b return bend $32.00-$34.50 USD/Piece
CS butt welded 90DEG LR elbow $0.50-$10.00 USD/Piece
Tube Weld 180 deg return bend $1.00-$200.00 USD/Piece
stainless steel 180 degree return bend $6.10-$7.60 USD/Kilogram
180 degree long radius return bend $1.00-$50.00 USD/Piece
Copper Return Bends CxC,180degree $0.10-$50.00 USD/Piece
Sanitary Steel 180 degree long welding bend $1.00-$500.00 USD/Piece
180 degree copper return bend $0.10-$2.00 USD/Piece
ASME B16.9 Sch 40 180 Degree Return Bend $0.10-$10.00 USD/Piece
stainless steel clamp 180 degree return bends $2.00-$10.00 USD/Piece
CS pipe fitting 180 degree return bend $1.00-$15.00 USD/Piece
180 Degree return bend with weld ends $0.50-$25.00 USD/Piece
180 Returns Schedule 40 dn 150 Bend $14.00-$15.00 USD/Piece

Reference:alibaba

Buttweld ANSI/ASME B16.9 180 Degree Return Bends Dimensions:

Nominal   Pip     Size    (NPS) DN Outside  Diameter at Bevel Center- to-Center D Back-to-Face K
Long Radius Short Radius Long Radius Short Radius
1/2 15 21.3 76   48
3/4 20[Note(3)] 26.7 76   51
1 25 33.4 76 51 56 41
1-1/4 32 42.2 95 64 70 52
1-1/2 40 48.3 114 76 83 62
2 50 60.3 152 102 106 81
2-1/2 65 73.0 190 127 132 100
3 80 88.9 229 152 159 121
3-1/2 90 101.6 267 178 184 140
4 100 114.3 305 203 210 159
5 125 141.3 381 254 262 197
6 150 168.3 457 305 313 237
8 200 219.1 610 406 414 313
10 250 273.0 762 508 518 391
12 300 323.8 914 610 619 467
14 350 355.6 1067 711 711 533
16 400 406.4 1219 813 813 610
18 450 457 1372 914 914 686
20 500 508 1524 1016 1016 762
22 550 559 1676 1118 1118 838
24 600 610 1829 1219 1219 914

All dimensions are in millimeters.

NOTES:

(1) Above all dimensions are in millimeters.
(2) Dimension A is equal to one-half of dimension O.
(3) O and K dimensions of 55mm and 43mm,respectively,mat be furnished for NPS 3/4(DN20)at the manufacture’s option.
