Butt weld ASME B16.9 Short Stub End Manufacturer


Leading ANSI/ASME B16.9 Butt weld Short Stub End Manufacturers and Authoritative Short Pattern Stub End Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Short Stub End Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld stub end short length, we are providing high-quality short pattern lap joint stub end at best price in India.

We keep the largest stock of short stub ends, stainless steel short stub end, carbon steel short stub end, nickel alloy short stub end, alloy steel short stub end, monel short stub end, copper short stub end in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD SHORT STUB END / STAINLESS STEEL BUTT WELD SHORT STUB END / DUPLEX STEEL BUTT WELD SHORT STUB END / CARBON STEEL BUTT WELD SHORT STUB END / ALLOY STEEL BUTT WELD SHORT STUB END / HASTELLOY STEEL BUTT WELD SHORT STUB END / MONEL STEEL BUTT WELD SHORT STUB END / INCONEL STEEL BUTT WELD SHORT STUB END / TITANIUN STEEL BUTT WELD SHORT STUB END / SUPER DUPLEX STEEL BUTT WELD SHORT STUB END / INCOLOY STEEL BUTT WELD SHORT STUB END / ALLOY 20 BUTT WELD SHORT STUB END / 254 SMO BUTT WELD SHORT STUB END/ COPPER NICKEL STEEL BUTT WELD SHORT STUB END
ANSI/ASME B16.9 Butt weld Short Stub End Exporter in India

ANSI/ASME B16.9 Butt weld Short Stub End Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Short Stub End Materials and Grade

Stainless Steel Butt weld Short Stub End:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Short Stub End:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Short Stub End:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Short Stub End:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Short Stub End in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Short Stub End. We keep intensive stock of Short Pattern Stub End Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Short Stub End. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Short Stub End Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, short stub end or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Short Stub End Price List

Following is ANSI/ASME B16.9 Butt weld Short Stub End price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Butt Weld Fitting Stainless Steel Short Stub End $1.00-$100.00 USD/Piece
Butt Welding MSS SP-43 Short Type Stub End $0.10-$20.00 USD/Piece
carbon steel long pipe Stub End $2.03-$53.00 USD/Piece
stub end short 3″ NPS stainless steel sch 10 $1.00-$10.00 USD/Piece
Short Type Butt Welding 1″ Sch10s Stub End $0.10-$20.00 USD/Piece
Copper nickel pipe short collar rj stub end $1.00-$100.00 USD/Piece
Short Stub End $15.00-$100.00 USD/Piece
Carbon Steel Butt Weld Short Stub End Fittings $1.00-$10.00 USD/Piece
Alloy Steel Short Stub End $4.00-$6.00 USD/Piece
Sch10s Pure Nickel Short Stub Ends For Industrial $6.00-$1000.00 USD/Piece
gr2 short type 3″ titanium stub end $12.00-$136.00 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Short Stub End Dimensions:

Nominal Pipe Size Outside diameter
of barrel
Length (F) Radius (R) Diameter (G)
Minimum Maximum Long
Pattern
Short
Pattern
1/2" 20.5 22.8 76 51 3 35
3/4" 25.9 28.1 76 51 3 43
1" 32.6 35.0 102 51 3 51
1 1/4" 41.4 43.6 102 51 5 64
1 1/2" 47.5 49.9 102 51 6 74
2" 59.5 62.4 152 64 8 92
2 1/2" 72.2 75.3 152 64 8 105
3" 88.1 91.3 152 64 10 127
3 1/2" 100.8 104.0 152 76 10 140
4" 113.5 116.7 152 76 11 157
5" 140.5 144.3 203 76 11 186
6" 167.5 171.3 203 89 13 216
8" 218.3 222.1 203 102 13 270
10" 272.3 277.2 254 127 13 324
12" 323.1 328.0 254 152 13 381
14" 354.8 359.9 305 152 13 413
16" 405.6 411.0 305 152 13 470
18" 456.0 462.0 305 152 13 533
20" 507.0 514.0 305 152 13 584
22" 558.0 565.0 305 152 13 641
24" 609.0 616.0 305 152 13 692

Butt weld ASME B16.9 Short Stub End Dimensional Tolerances:

Nominal Pipe Size 1/2 up to 2½ 3 to 3½ 4 5 to 8 10 to 18 20 to 24
Outside Diameter at Welding End (OD) + 1.6
– 0.8
1.6 1.6 + 2.29
– 1.6
+ 4.06
– 3.05
+ 6.35
– 4.83
Overall Length (F) 1.6 1.6 1.6 1.6 2 2
Outside Diameter of Lap (G) + 0
– 0.76
+ 0
– 0.76
+ 0
– 0.76
+ 0
– 0.76
+ 0
– 1.6
+ 0
– 1.6
Thickness of Lap (T) + 1.52
– 0
+ 1.52
– 0
+ 1.52
– 0
+ 1.52
– 0
+ 1.52
– 0
+ 1.52
– 0
Fillet Radius of Lap (R) + 0
– 0.76
+ 0
– 0.76
+ 0
– 1.6
+ 0
– 1.6
+ 0
– 1.6
+ 0
– 1.6
Wall Thickness (t) Not less than 87.5% of Nominal Wall Thickness

ANSI B16.9 Short Stub End Tolerances:

DIMENSIONAL TOLERANCES -Short Stub Ends
For all fittings Stub Ends
Nominal Pipe Size (NPS) Outside Ø at Bevel Indide Ø at End Wall Thickness
t / t1
O.D. of Lap G Fillet Radius of Lap – R Overall Length. – F
1/2 a 2 1/2 1 0,8 Not +0 -1 +0 -1 2
3 a 3 1/2 1 1,6 less +0 -1 +0 -1 2
4 +2 -1 1,6 than +0 -1 +0 -2 2
5 a 6 +3 -1 1,6 87,50% +0 -1 +0 -2 2
8 2 1,6 of nominal +0 -1 +0 -2 2
10 +4 -3 3,2 tickness +0 -2 +0 -2 2
12 to 18 +4 -3 3,2 +0 -2 +0 -2 3
20 a 24 +6 -5 4,8 +0 -2 +0 -2 3
26 a 30 +7 -5 4,8
32 a 48 +7 -5 4,8

ANSI/ASME B16.9 Butt weld Short Stub End Application
