Butt weld ASME B16.9 Stub End Manufacturer


Leading ANSI/ASME B16.9 Butt weld Stub End Manufacturers and Authoritative SS Stub End Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Stub End Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld stub end fittings we are providing high-quality buttweld stub end pipe fitting at best price in India.

We keep the largest stock of buttweld stub end pipe, stainless steel stub end, carbon steel stub end, nickel alloy stub end, alloy steel stub end, monel stub end, copper stub end, stub end fitting in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD STUB END / STAINLESS STEEL BUTT WELD STUB END / DUPLEX STEEL BUTT WELD STUB END / CARBON STEEL BUTT WELD STUB END / ALLOY STEEL BUTT WELD STUB END / HASTELLOY STEEL BUTT WELD STUB END / MONEL STEEL BUTT WELD STUB END / INCONEL STEEL BUTT WELD STUB END / TITANIUN STEEL BUTT WELD STUB END / SUPER DUPLEX STEEL BUTT WELD STUB END / INCOLOY STEEL BUTT WELD STUB END / ALLOY 20 BUTT WELD STUB END / 254 SMO BUTT WELD STUB END/ COPPER NICKEL STEEL BUTT WELD STUB END
ANSI/ASME B16.9 Butt weld Stub End Exporter in India

ANSI/ASME B16.9 Butt weld Stub End Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Stub End Materials and Grade

Stainless Steel Butt weld Stub End:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Stub End:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Stub End:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Stub End:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Stub End in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Stub End. We keep intensive stock of Stub End Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Stub End. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Stub End Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, stub end or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Stub End Price List

Following is ANSI/ASME B16.9 Butt weld Stub End price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
SS Butt welded Stub End Pipe Fittings $0.80 USD/Piece
Stub End Butt Weld Pipe Fitting $1.00-$10.00 USD/Piece
ANSI B16.9 butt welded lap joint stub end $10.00-$100.00 USD/Piece
Sanitary SS pipe lap joint flange butt weld Stub End $3.00-$50.00 USD/Piece
butt welded carbon steel stub end $0.01-$9.00 USD/Piece
DN200 Butt Welding Stub End $1.98-$700.00 USD/Piece
stainless steel 316 butt welding stub end $1.00-$100.00 USD/Piece
ASME B16.5 150lb Stub Ends $1.80-$400.00 USD/Piece
pipe fitting stub end 1″ $6.10-$7.60 USD/Piece
gr2 titanium stub end $10.00-$150.00 USD/Piece
Butt Weld Long Stub End $1.00-$100.00 USD/Piece
Butt Weld Long Stub End $3.50-$35.00 USD/Piece
butt welding stub end $10.00-$30.00 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Stub End Dimensions:

Nominal Pipe Size Outside diameter
of barrel
Length (F) Radius (R) Diameter (G)
Minimum Maximum Long
Pattern
Short
Pattern
1/2" 20.5 22.8 76 51 3 35
3/4" 25.9 28.1 76 51 3 43
1" 32.6 35.0 102 51 3 51
1 1/4" 41.4 43.6 102 51 5 64
1 1/2" 47.5 49.9 102 51 6 74
2" 59.5 62.4 152 64 8 92
2 1/2" 72.2 75.3 152 64 8 105
3" 88.1 91.3 152 64 10 127
3 1/2" 100.8 104.0 152 76 10 140
4" 113.5 116.7 152 76 11 157
5" 140.5 144.3 203 76 11 186
6" 167.5 171.3 203 89 13 216
8" 218.3 222.1 203 102 13 270
10" 272.3 277.2 254 127 13 324
12" 323.1 328.0 254 152 13 381
14" 354.8 359.9 305 152 13 413
16" 405.6 411.0 305 152 13 470
18" 456.0 462.0 305 152 13 533
20" 507.0 514.0 305 152 13 584
22" 558.0 565.0 305 152 13 641
24" 609.0 616.0 305 152 13 692

Note: The dimensions are in millimeters
Source : ASME B16.9 – 2007

Butt weld Stub End – ANSI and MSS SP-43 Dimensions:

STUB ENDS – ANSI B 16.9 and MSS SP-43 dimension
inches ND mm Diameter of lap Radius of fillet Length F
D G R R1 MSS SP43 ANSI B16.9
1/2 15 21,34 34,92 3,17 0,80 50,80 76,20
3/4 20 26,67 42,86 3,17 0,80 50,80 76,20
1 25 33,40 50,80 3,17 0,80 50,80 101,60
1 1/4 32 42,16 63,50 4,76 0,80 50,80 101,60
1 1/2 40 48,26 73,00 6,35 0,80 50,80 101,60
2 50 60,32 92,10 7,93 0,80 63,50 152,40
2 1/2 65 73,02 104,80 7,93 0,80 63,50 152,40
3 80 88,90 127,00 9,52 0,80 63,50 152,40
3 1/2 90 101,60 139,70 9,52 0,80 76,20 152,40
4 100 114,30 157,20 11,11 0,80 76,20 152,40
5 125 141,30 185,70 11,11 1,58 76,20 203,20
6 150 168,27 215,90 12,70 1,58 88,90 203,20
8 200 219,07 269,80 12,70 1,58 101,60 203,20
10 250 273,05 323,80 12,70 1,58 127,00 254,00
12 300 323,85 381,00 12,70 1,58 152,40 254,00
14 350 355,60 412,70 12,70 1,58 152,40 304,80
16 400 406,40 469,90 12,70 1,58 152,40 304,80
18 450 457,20 533,40 12,70 1,58 152,40 304,80
20 500 508,00 584,20 12,70 1,58 152,40 304,80
22 550 558,80 641,30 12,70 1,58 152,40 304,80
24 600 609,60 692,10 12,70 1,58 152,40 304,80
The lap thickness T shall not be less than nominal pipe wall thickness

Butt weld Stub End – ANSI B16.9 Tolerances:

DIMENSIONAL TOLERANCES – STUB ENDS
For all fittings Stub Ends
Nominal Pipe Size (NPS) Outside Ø at Bevel Indide Ø at End Wall Thickness
t / t1
O.D. of Lap G Fillet Radius of Lap – R Overall Length. – F
1/2 a 2 1/2 1 0,8 Not +0 -1 +0 -1 2
3 a 3 1/2 1 1,6 less +0 -1 +0 -1 2
4 +2 -1 1,6 than +0 -1 +0 -2 2
5 a 6 +3 -1 1,6 87,50% +0 -1 +0 -2 2
8 2 1,6 of nominal +0 -1 +0 -2 2
10 +4 -3 3,2 tickness +0 -2 +0 -2 2
12 to 18 +4 -3 3,2 +0 -2 +0 -2 3
20 a 24 +6 -5 4,8 +0 -2 +0 -2 3
26 a 30 +7 -5 4,8
32 a 48 +7 -5 4,8

ANSI/ASME B16.9 Butt weld Stub End Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld Stub End and supplying to various core industries like

Chemicals Fertilizers Industries
