Buttweld ASME B16.9 Swage Nipple Manufacturer


Leading ANSI/ASME B16.9 Butt weld Swedge Nipple Manufacturers and Authoritative SS Swage Nipples Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Swedge Nipple Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld swedge nipple, we are providing high-quality swage nipple and pipe nipple at best price in India.

We keep the largest stock of stainless steel swage fittings, carbon steel swage nipples, nickel alloy swage nipples, alloy steel swage nipples, monel swage nipples in all dimensions.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD SWEDGE NIPPLE / STAINLESS STEEL BUTT WELD SWEDGE NIPPLE / DUPLEX STEEL BUTT WELD SWEDGE NIPPLE / CARBON STEEL BUTT WELD SWEDGE NIPPLE / ALLOY STEEL BUTT WELD SWEDGE NIPPLE / HASTELLOY STEEL BUTT WELD SWEDGE NIPPLE / MONEL STEEL BUTT WELD SWEDGE NIPPLE / INCONEL STEEL BUTT WELD SWEDGE NIPPLE / TITANIUN STEEL BUTT WELD SWEDGE NIPPLE / SUPER DUPLEX STEEL BUTT WELD SWEDGE NIPPLE / INCOLOY STEEL BUTT WELD SWEDGE NIPPLE / ALLOY 20 BUTT WELD SWEDGE NIPPLE / 254 SMO BUTT WELD SWEDGE NIPPLE/ COPPER NICKEL STEEL BUTT WELD SWEDGE NIPPLE
ANSI/ASME B16.9 Butt weld Swedge Nipple Exporter in India

ANSI/ASME B16.9 Butt weld Swedge Nipple Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Swedge Nipple Materials and Grade

Stainless Steel Butt weld Swedge Nipple:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Swedge Nipple:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Swedge Nipple:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Swedge Nipple:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Specification Compliance Data for Swage Nipples

End Connections
Threads ANSI/ASME B1.20.1
  API 5B
Beveled Ends ANSI B16.9
Square Cut Ends ANSI B16.11

Swage Nipples
Stainless ASME/ASTM SA403WP
Low Temp ASME/ASTM SA403WP
Nickel Alloy ASME/ASTM SB366

Materials
Stainless ASME/ASTM SA312 & 182
Chrome & Low Temp ASME/ASTM SA335, 333, 182, 350
Nickel Alloy ASME/ASTM SB161, 165, 163, 407, 464, 622, 160, 164, 166, 408, 473, 619

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Swedge Nipple in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Buttweld Swedge Nipple. We keep intensive stock of Swedge Nipple Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Swedge Nipple. We have over 4 decades of experience in manufacturing of both Seamless & Welded Swedge Nipple Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, pipe cap or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Swedge Nipple Price List

Following is ANSI/ASME B16.9 Butt weld Swedge Nipple price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Swage Nipple $10.00-$100.00 USD/Piece
Buttweld Nipple $200.00-$500.00 USD/Ton
Stainless Steel Swage Nipple Pipe Fittings $20.00-$100.00 USD/Box
Alloy Steel Swage Nipple Pipe Fittings $20.00-$100.00 USD/Box
Duplex Steel Swage Nipple Pipe Fittings $20.00-$100.00 USD/Box
Carbon Steel Nipple Pipe Fittings $20.00-$100.00 USD/Box
Swage Pipe Nipple $1.00-$50.00 USD/Set

Reference:alibaba

ASME B16.9 Butt weld Swedge Nipple Dimensions:

Dimensions – Seamless Swage Nipples

I.D. or Nominal Size Outside Diameter Length
NU EUE NU EUE
1/8
1/4 .540 2 1/4
3/8 .675 2 1/2
1/2 .840 2 3/4
3/4 1.050 3
1 1.315 1.469 3 1/2 4 1/2
1 1/4 1.660 1.812 4 6



I.D. or Nominal Size Outside Diameter Length
NU EUE NU EUE
1 1/2 1.900 2.094 4 1/2 6
2 2.375 2.594 6 1/2 8
2 1/2 2.875 3.094 7 8
3 3.500 3.750 8 8
3 1/2 4.000 4.250 8 8
4 4.500 4.750 9 9

ANSI/ASME B16.9 Butt weld Swedge Nipple Application
