Buttweld ASME B16.9 Welded Elbow Manufacturer


Leading ANSI/ASME B16.9 Welded Elbows Manufacturers and Authoritative SS Welded Elbow Supplier in India and Overseas.

ANSI/ASME B16.9 Welded Elbows Manufacturers in India

As a leading manufacturer, stockist, and exporters of buttweld ASME B16.9 welded elbow fittings, welded pipe elbows, welded steel elbows are provided at an affordable price in India.

We keep the largest stock of Stainless Steel Welded Elbows, Butt weld Welded Elbow, Nickel Alloy Welded Elbow, ASME B16.9 Butt weld Welded Elbow, Carbon Steel Welded Elbow, Alloy steel Welded Elbow, Monel Welded Elbow, Inconel Welded Elbow.

Contact Us

WE ARE MANUFACTURING ANSI/ASME B16.9 WELDED ELBOWS / STAINLESS STEEL WELDED ELBOWS / DUPLEX STEEL WELDED ELBOWS / CARBON STEEL WELDED ELBOWS / ALLOY STEEL WELDED ELBOWS / HASTELLOY STEEL WELDED ELBOWS / MONEL STEEL WELDED ELBOWS / INCONEL STEEL WELDED ELBOWS / TITANIUN STEEL WELDED ELBOWS / SUPER DUPLEX STEEL WELDED ELBOWS / INCOLOY STEEL WELDED ELBOWS / ALLOY 20 WELDED ELBOWS / 254 SMO WELDED ELBOWS/ COPPER NICKEL STEEL WELDED ELBOWS
ANSI/ASME B16.9 Welded Elbows Exporter in India

ANSI/ASME B16.9 Welded Elbows Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Welded Elbows Materials and Grade

Stainless Steel ANSI/ASME B16.9 Welded Elbows:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel ANSI/ASME B16.9 Welded Elbows:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy ANSI/ASME B16.9 Welded Elbows:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel ANSI/ASME B16.9 Welded Elbows:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Welded Elbows in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of welded elbow fittings. We keep intensive stock of ss welded elbows to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of welding Elbows. We have over 4 decades of experience in manufacturing of stainless steel welded elbows using high quality of raw materials and latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Welded Elbows Price List

Following is ANSI/ASME B16.9 Welded Elbows price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
90 degree Sanitary welding Pipe Fittings Elbow $1.00-$300.00 USD/Piece
stainless steel butt welded pipe fitting elbow $15.00-$20.00 USD/Piece
Carbon Steel Welded Elbow $1.00-$15.00 USD/Piece
CS butt welded 90DEG LR elbow $0.50-$10.00 USD/Piece
welded pipe elbow DN 100 4″ sch 40 $6.10-$7.60 USD/Kilogram
Long sweep butt welded 30 degree elbow $0.60-$500.00 USD/Piece
stainless steel welding 180 degree elbow $1.00-$100.00 USD/Piece
316 welded pipe fittings elbow $1.00-$10.00 USD/Piece
Sanitary Stainless Steel Welded Pipe Fitting Elbow $10.00-$100.00 USD/Piece
butt welded pipe 6061 t6 aluminum elbow $0.20-$180.00 USD/Piece
low temperature carbon steel welded fittings elbow $1.00-$1000.00 USD/Piece
ASME B16.9 welded elbow pipe fittings $1.00-$100.00 USD/Piece
Butt Welded Elbow with standard ANSI DIN JIS SGP $0.55-$100.28 USD/Piece
22 1/2″ degree elbow welding $0.20-$20.00 USD/Piece
DIN/EN welded dn700 steel elbow $3.00-$800.00 USD/Piece

Reference:alibaba

Buttweld ANSI/ASME B16.9 Welded Elbows Dimensions:

Nominal Pipe Size (NPS) DN Outside Diameter at Bevel Center- to-Center O Back-to-Face K
1 25 33.4 51 41
1-1/4 32 42.2 64 52
1-1/2 404 8.3 76 62
2 50 60.3 102 81
2-1/2 65 73.0 127 100
3 80 88.9 152 121
3-1/2 90 101.6 178 140
4 100 114.3 203 159
5 125 141.3 254 197
6 150 168.3 305 237
8 200 219.1 406 313
10 250 273.0 508 391
12 300 323.8 610 467
14 350 355.6 711 533
16 400 406.4 813 610
18 450 457 914 686
20 500 508 1016 762
22 550 559 1118 838
24 600 610 1219 914

NOTES:

(1). Above all dimensions are in millimeters.
(2). Dimension A is equal to one-half of dimension O.

ANSI/ASME B16.9 Welded Elbows Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Welded Elbows and supplying to various core industries like

Chemicals Fertilizers Industries
