Manufacturer of Reducing Cross Pipe Fitting as per ASTM/ASME/ANSI A182, B564, B366, A105 and Straight/Equal Cross Fitting Supplier in India.
Manufacturers, Stockist, Supplier, and Exporter of Straight Cross Pipe Fitting, Equal Cross Pipe Fitting, Stainless Steel Pipe Cross, Alloy Steel Pipe Cross and Carbon Steel Pipe Cross.
Largest Stock of Cross Pipe Fitting, Welded Cross, Threaded Cross Pipe Fitting, Butt weld Cross Pipe Fittings, Straight Cross Fitting at Best Prices in India.
- What is Cross Pipe Fitting ?
- Equal Cross Pipe Fitting Specifications
- Straight Cross Pipe Fitting Price in India
- Why Choose M P Jain Tubing Solutions LLP
- Butt Weld Fittings Types
- Various Applications of Reducing Cross Fitting
- Types of Cross Pipe Fitting
- Cities We Export Equal Cross Pipe Fitting
- Countries We Export Equal Cross Pipe Fitting
What is Reducing Cross Pipe Fitting ?
The Reducing Cross Pipe Fitting also called as unequal pipe cross, it is the pipe cross which have four branch ends are not in the same diameters.
Crosses, also known as four-way fittings or cross branch lines, have one inlet and three outlets (or vice versa), and often have solvent-welded socket or female-threaded ends. Cross fittings may stress pipes as temperatures change, because they are at the center of four connection points. A tee is steadier than a cross; it behaves like a three-legged stool, and a cross behaves like a four-legged stool. Geometrically, any three non-collinear points can self-consistently define a plane; three legs are inherently stable, whereas four points overdetermine a plane, and can be inconsistent, resulting in physical stress on a fitting.
Reducing Cross Pipe Fitting Specifications
Butt Welded Pipe Cross Fittings Production Range
Outside Diameter: Seamless Cross Fitting ( 1/2″～24″), ERW / Welded / Fabricated Cross Fitting (1/2″～48″)
Type: Seamless, Welded, Equal Cross, Reducing Cross
Wall Thickness: 3mm – 40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Value Added Services: Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering
Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel
ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2
ASTM A403 – ASME SA403 – Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASME B16.9 – Factory-Made Wrought Fittings Buttwelding
ASME B16.25 – Buttwelding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Buttwelding Returns
MSS SP-43 – Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Pipe Cross Material Grades
Stainless Steel Pipe Cross; ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Pipe Cross: ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Pipe Cross: ASTM A420 WPL3, A420 WPL6
Alloy Steel Pipe Cross: ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Pipe Cross: ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462
Nickel Alloy Pipe Cross: ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )
Why Choose M P Jain Tubing Solutions LLP
M P Jain Tubing Solutions LLP is dominant Manufacturer, Stockist, and Exporter of cross pipe fittings in Mumbai, India since 1972. We positions in Top 50 organization in India and active in manufacturing of reducing cross pipe fitting and straight cross fitting. While, there are numerous specific kinds of fittings which can be produced, the most widely recognized sorts of fittings which we manufactured and stock like straight cross pipe fitting, equal cross pipe fitting.
We are leading Suppliers of the high-quality scope of stainless steel cross pipe fittings that are fabricated under the master direction of our persevering workforce. Having more than 45 years of experience and brief knowledge our ss cross & all other products are manufactured using best quality material and go through a detailed quality check at every stage of production to make sure that end product meets all quality requirements of our company. Outlined consistency with international quality standards, these stainless steel pipe cross are corrosion resistance, sturdy and durable. we also export butt weld cross pipe fittings in customized size and shape. we are also active in the manufacturing and distribution of welded cross in India and overseas. we also provide a complete range of threaded cross pipe fitting, straight cross fitting, reducing cross pipe fittings as per clients specifications
Trusted Supplier of Pipe Cross – Straight/equal Cross, Reducing Cross
Manufacturer / Stockist / Exporter in India | ASME/ANSI B16.9, ANSI B16.28, MSS-SP-43
Carbon, Alloy, Stainless Steel pipe cross fittings
Reducing Cross Pipe Fitting Price List
Following is reducing cross pipe fitting price in India.This price range is also depends on minimum order and might be varies without any prior information.For more details contact us now and get Instant Quote.
|Threaded pipe fittings Welded Cross||$0.09-$10.00||USD/Piece|
|SS Cross Butt Welded Pipe Fitting||$26.00-$700.00||USD/Piece|
|stainless steel 4-way cross pipe fitting||$42.00-$480.00||USD/Piece|
|High Strength pipe fittings cross||$0.03-$5.00||USD/Piece|
|bsp galvanised malleable iron pipe fittings cross||$0.40-$1.80||USD/Piece|
|Carbon Steel Pipe Fittings 4 Way Cross||$3.00-$10.00||USD/Piece|
|sanitary stainless steel 4 way pipe fitting weld cross||$2.80-$3.00||USD/Piece|
|four way equal copper cross pipe fittings||$1.37-$2.74||USD/Piece|
|Oil gas companies cross Pipe Fittings||$0.03-$10.00||USD/Piece|
|hydraulic ferrule cross 4 way pipe fitting||$5.56-$20.21||USD/Piece|
|4-way Hygenic Stainless Steel Welded Pipe Fitting||$3.89-$3.97||USD/Piece|
|pipe fitting reducing cross threaded||$0.99-$99.99||USD/Piece|
|Galvanized Reducing Cross Pipe Fittings||$0.17-$8.00||USD/Piece|
|stainless steel straight cross pipe fittings||$2.69-$28.09||USD/Piece|
|4-way Straight cross||$4.00-$389.00||USD/Piece|
|Straight Cross high pressure pipe fittings||$1.00-$10.00||USD/Piece|
|equal/straight carbon steel pipe fittings cross||$1.00-$500.00||USD/Piece|
|asme b16.9 butt welding sch40 3 inch straight cross steel pipe fittings||$0.10-$10.00||USD/Piece|
Types of Butt Weld Fittings
Various Applications of Reducing Cross Pipe Fitting:
- Gas compression and distribution industries
- Industrial equipment
- Utilities/power generation
- Waste treatment
- Chemical processing
Types of Cross Pipe Fittings
Equal Cross Pipe Fitting
The equal pipe cross is one type of the pipe cross, just like a equal tee, the equal crosses means all the 4 ends of the cross are in same diameter. The pipe cross, like a road cross, is the joint of 4 pipes. Receiving the pressure from the 4 pipes, the weld joint between the pipes and cross must be very strong.
Reducing Cross Pipe Fitting
The reducing cross also is called unequal cross pipe fittings, it’s a pipe cross which has four branch ends are not in the same diameters. just like a unequal tee, the reducing cross connect the pipes of different diameters.
Cities We Export Reducing Cross Pipe Fitting
Countries We Export Reducing Cross Pipe Fitting
