Steel Pipe End Caps Manufacturer


Manufacturer of Steel Pipe End Caps as per ASTM/ASME/ANSI A182, B564, B366, A105 and Steel Pipe Caps/Plugs Suppliers in India.

Steel Pipe End Caps Manufacturers in India

Manufacturers, Stockist, Supplier, and Exporter of Pipe End Cap, Stainless Steel Pipe Caps, Alloy Steel Pipe Caps and Carbon Steel Pipe Caps.

Largest Stock of Weld On Pipe Caps, Threaded Pipe Cap, 1 inch Pipe Cap, 1.5 inch Pipe Cap, 2 inch Pipe Cap, 3 inch Pipe Cap, 4 inch Pipe Cap, 6 inch Pipe Cap, 5 inch Pipe Cap, 8 inch Pipe Cap at Best Prices in India.

Contact Us

WE ARE MANUFACTURING STEEL PIPE END CAPS / STAINLESS STEEL PIPE CAPS / DUPLEX STEEL PIPE CAPS / CARBON STEEL PIPE CAPS / ALLOY STEEL PIPE CAPS / HASTELLOY STEEL PIPE CAPS / MONEL STEEL PIPE CAPS / INCONEL STEEL PIPE CAPS / TITANIUN STEEL PIPE CAPS / SUPER DUPLEX STEEL PIPE CAPS / INCOLOY STEEL PIPE CAPS / ALLOY 20 PIPE CAPS / 254 SMO PIPE CAPS/ COPPER NICKEL STEEL PIPE CAPS / STEEL PIPE CAPS AND PLUGS / WELD ON PIPE CAPS / PIPE END CAP / THREADED PIPE CAP / 1 INCH PIPE CAP / 1.5 INCH PIPE CAP / 2 INCH PIPE CAP / 3 INCH PIPE CAP / 4 INCH PIPE CAP / 6 INCH PIPE CAP / 5 INCH PIPE CAP / 8 INCH PIPE CAP
Stainless Steel Pipe End Caps Exporter in India

What is Steel Pipe End Caps ?

Steel Pipe End Caps, usually liquid- or gas-tight, cover the otherwise open end of a pipe. A caps attaches to the exterior of a pipe, and may have a solvent-weld socket end or a female-threaded interior. The exterior of an industrial cap may be round, square, rectangular, U- or I-shaped, or may have a handgrip. If a solvent-weld cap is used to provide for a future connection point, several inches of pipe must be left before the cap; when the cap is cut off for the future connection, enough pipe must remain to allow a new fitting to be glued onto it.

Common Shapes of pipe caps

  • Round
  • Square
  • Rectangular
  • “U” Shape Cap
  • “I” Shape Cap
  • Hex Cap etc.

Reference:wikipedia

Steel Pipe End Caps Specifications

Buttweld Pipe End Cap Production Range

Outside Diameter: 1/2″ – 48″

Wall Thickness: 2-40 mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Value Added Services: Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering

Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel

Manufacturing Standards

ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43

DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

EN: EN10253-1, EN10253-2

ASTM A403 – ASME SA403 – Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings

ASME B16.9 – Factory-Made Wrought Fittings Buttwelding

ASME B16.25 – Buttwelding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Buttwelding Returns

MSS SP-43 – Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Pipe Cap Material Grades

Stainless Steel Pipe Cap; ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Carbon Steel Pipe Cap: ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Low Temperature Carbon Steel Pipe Cap: ASTM A420 WPL3, A420 WPL6

Alloy Steel Pipe Cap: ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91

Duplex Steel Pipe Cap: ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462

Nickel Alloy Pipe Cap: ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is dominant Manufacturer, Stockist, and Exporter of stainless steel pipe end caps in Mumbai, India since 1972. We positions in Top 50 organization in India and active in manufacturing of steel pipe caps/plugs. While, there are numerous specific kinds of fittings which can be produced, the most widely recognized sorts of fittings which we manufactured and stock like Weld On Pipe Caps, Threaded Pipe Cap, 1 inch Pipe Cap, 1.5 inch Pipe Cap, 2 inch Pipe Cap, 3 inch Pipe Cap, 4 inch Pipe Cap, 6 inch Pipe Cap, 5 inch Pipe Cap, 8 inch Pipe Cap and many more. we also manufacturer pipe caps and plugs as per clients specifications

Trusted Supplier of Pipe End Caps – Round, Oval

Manufacturer / Stockist / Exporter in India | ASME/ANSI B16.9, ANSI B16.28, MSS-SP-43

Carbon, Alloy, Stainless Steel pipe caps and plugs

Steel Pipe End Caps Price List

Following is steel pipe end caps price in India.This price range is also depends on minimum order and might be varies without any prior information.For more details contact us now and get Instant Quote.
Materials Price Range Unit
Large steel pipe end cap $2.00-$20.00 USD/Piece
stainless steel pipe end cap $100.00-$3000.00 USD/Piece
socket weld end cap $0.17-$8.00 USD/Piece
threaded pipe galvanized pipe end cap $0.17-$8.00 USD/Piece
carbon steel end cap $50.00-$200.00 USD/Piece
weld on pipe cap $72.00-$75.00 USD/Piece
B16.9 sch40 ss pipe fitting butt weld end cap $10.00-$50.00 USD/Piece
Large diameter welded carbon steel pipe end cap sch80 $0.50-$10.00 USD/Piece
18 inch welded stainless steel pipe end cap $1000.00-$3000.00 USD/Ton
Stainless steel casting pipe end Cap $1.00-$20.00 USD/Piece
Stainless Steel Sanitary Pipe End Cap $3.89-$3.97 USD/Piece
2 inch stainless steel pipe fitting end cap $600.00-$800.00 USD/Ton
AISI304 stainless steel pipe end cap $0.50-$5.00 USD/Piece
ASME 8 inch steel pipe caps $0.10-$28.09 USD/Piece
pipe end cap $50.00-$200.00 USD/Piece
High Quality Large Steel Pipe End Cap $4.00-$389.00 USD/Piece
seamless carbon steel pipe end cap $0.80-$100.00 USD/Piece
Stainless Steel Pipe Plug $1.00-$10.00 USD/Piece

Reference:alibaba

Types of Buttweld Fittings

Various Applications of Steel Pipe End Caps:

  • Gas compression and distribution industries
  • Automotive
  • Industrial equipment
  • Utilities/power generation
  • Marine
  • Waste treatment
  • Textile
  • Refining
  • Pulp/paper
  • Petroleum
  • Chemical processing

Types of Steel Pipe End Caps

Threaded Caps

These caps are female threaded. The thread can be either straight or tapered, also referred as NPT. Generally, plugs have a male thread and caps have a female thread.

Anti-roll Caps

These caps are round in shape with a slightly square end. This prevents pipes and tubes from rolling.

Tapered Caps

These caps have tapered sides, which offers a close fit. Some of these fittings can be used either as a cap or a plug. Tapered caps and plugs are multi-functional and go well with male and female NPT threads, straight tubes and bars; and male straight threads.

Features of pipe caps

There are several important specifications that the buyer should consider before making bulk purchase of pipe caps. The important specifications that needs to be considered are

  • BSP (British Standard Pipe) size: This size option is applicable only for round shaped caps, wherein the object to be capped has a male BSP thread.
  • NPT (National Pipe Thread ) size: This feature is applicable for round shaped caps, wherein the object that has to be protected has a male NPT thread.
  • Diameter: Diameter is an important dimension that is applicable only for round caps and plugs. In case of fittings having straight threads, the most important feature to be considered is the major thread diameter. However, this dimension is not an important consideration when cap, plug or object to be capped has a tapered (NPT or BSP) thread.
  • Shape: The dimension and shape of pipe caps are also very important points to consider. Pipe caps of different shapes have different features. Some features are:
    • Square or Rectangular Cap: For square or rectangular caps, length and width are the most important dimensions to consider. For rectangular caps, the width is the smaller cross sectional dimension, whereas, for square caps, the length and breadth are the same dimension.
    • Round Caps: Popular features of round caps are: flange, slotted head, knurled or faceted head, retaining head, and tear tab. A flange is meant for easy removal or additional protection of pipe or tube surfaces. Flanges also help to prevent accidental pushing away of the plug through the opening. Slotted caps can be easily installed or removed with the help of a screwdriver. Knurled or faceted heads are usually designed for threaded caps and plugs only. Knurls or facets offer hassle free installation and removal. Pipe caps provided with a tear-tab or strip are easy to remove.
